Associated Numbers
16371 190.922.102 19176N 20432904OE 255521D 28100-31131 428000-6841 6040409 CST40409GS DSN1241 UD12019SSpecifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 189 mm |
| Mount Hole Center - Center (O.1) | 112 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 21.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | 4unner 4.0 | 01.2010-12.2015 | |
| TOYOTA | FJ Cruiser 4.0 | 01.2010-12.2013 | |
| TOYOTA | Land Cruiser 4.0 V6 Dual WTi | [1GR-FE] | 01.2010- |
| TOYOTA | Land Cruiser 4.0 V6 WTi | [1GR-FE] | 01.2010- |
| TOYOTA | Tundra 4.0 | 01.2011-12.2012 |
Reference Information
CST40409GS 16371 28100-31141 2810031130 28100-31131 6040409 UD12019S 20432904OE 255521D 190.922.102 19176N DSN1241 STR6283 428000-6841Video/Publications
16371 190.922.102 19176N 20432904OE 255521D 28100-31131 428000-6841 6040409 CST40409GS DSN1241 UD12019SAdd Your Number
