Associated Numbers
128000-6920 128000-6921 128000-6922 246-25213 28300-32980 28300-32980-71 91-29-5347 S-8515 UD11122S UNIT BOM 190-898Specifications
| Kilowatt | 4.5 kW |
| Length (L.1) | 298 mm |
| Mount Hole Center - Center (O.1) | 114 mm |
| Mount Hole Diameter (C.1) | 14.5 mm |
| Mount Hole Diameter (C.2) | 14.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 11 qty |
| Pinion at Rest (B) | 16 mm |
| Rotation | CW |
| Spigot Diameter (A) | 90 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Fork Lifts 5FD-33 | ||
| TOYOTA | Fork Lifts 5FD-33 | ||
| TOYOTA | Fork Lifts 5FD-35 | ||
| TOYOTA | Fork Lifts 5FD-35 | ||
| TOYOTA | Fork Lifts 5FD-38 | ||
| TOYOTA | Fork Lifts 5FD-38 | ||
| TOYOTA | Fork Lifts 5FD-40 | ||
| TOYOTA | Fork Lifts 5FD-40 | ||
| TOYOTA | Fork Lifts 5FD-45 | ||
| TOYOTA | Fork Lifts 5FD-45 | ||
| TOYOTA | Fork Lifts 5FDE-35 | ||
| TOYOTA | Fork Lifts 5FDE-35 |
Reference Information
128000-6921 128000-6922 BOM 128000-6920 28300-32980 UD11122S UNIT 28300-32980-71 91-29-5347 246-25213 S-8515 190-898Video/Publications
128000-6920 128000-6921 128000-6922 246-25213 28300-32980 28300-32980-71 91-29-5347 S-8515 UD11122S UNIT BOM 190-898Add Your Number
