Associated Numbers
36100-3A020 36100-3A030 36100-3A200 8000290 PXPSB-509 UD02067SSpecifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 217 mm |
| Mount Hole Center - Center (O.1) | 109 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | M10x1.25 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 11 qty |
| No./Teeth (Replaces) | 11 qty |
| Pinion at Rest (B) | 25 mm |
| Rotation | CW |
| Spigot Diameter (A) | 77 mm |
| Unit Type | DELCO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KIA | Borrego 3.0 CRDi | 01.2010- | |
| KIA | Mohave 3.0 CRDi | 01.2010- |
Reference Information
8000536 36100-3A020 8000290 36100-3A030 36100-3A200 UD02067S STD8233 EX361003A030 PXPSB-509Video/Publications
36100-3A020 36100-3A030 36100-3A200 8000290 8000536 EX361003A030 PXPSB-509 STD8233 UD02067SAdd Your Number
