Associated Numbers
93209031 F000AL0135 STB9320 UD20346SSpecifications
| Kilowatt | 2.2 kW |
| Length (L.1) | 251.5 mm |
| Mount Hole Center - Center (O.1) | 89.5 mm |
| Mount Hole Center - Center (O.2) | 127.5 mm |
| Mount Hole Center - Center (O.3) | 89.5 mm |
| Mount Hole Diameter (C.1) | 10.5 mm |
| Mount Hole Diameter (C.2) | 10.5 mm |
| Mount Hole Diameter (C.3) | 10.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 28.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 98 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CHEVROLET | 20 Serie Pickup 4.0 D | 01.1985-12.1997 | |
| CHEVROLET | Bonanza 4.0 D | 04.1988-10.1995 | |
| CHEVROLET | Veraneio 4.0 D | 01.1985-12.1997 |
Reference Information
STB9320 UD20346S F000AL0135 000F000AL0135 93209031Video/Publications
93209031 F000AL0135 STB9320 UD20346SAdd Your Number
