Associated Numbers
104210-3260 104210-3261 11038R 12571 25756440 554475RI 90-29-5538 A-80282 A-80325 ALN3261 ALN3261NW DRA1097 UD11371ASpecifications
| Amp | 150 A |
| Diameter (D.1) | 10 mm |
| Diameter (D.2) | 13 mm |
| Diameter (D.3) | 10 mm |
| Grooves | 5 qty |
| Length (L.1) | 175 mm |
| Mount Inside Length or Pad Mount C-C (C) | 30 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 58 mm |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Pad mount thickness (E.3) | 50 mm |
| Plug Code | PL_2200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 30.5 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CADILLAC | SRX 4.6 | 01.2004-12.2009 | |
| CADILLAC | SRX 4.6 AWD | [LH2] | 09.2003-12.2009 |
| CADILLAC | STS 4.4 | 01.2006-12.2009 | |
| CADILLAC | STS 4.4 Kompressor | [LC3] | 09.2005-12.2007 |
| CADILLAC | STS 4.4 Kompressor AWD | [LC3] | 09.2005-12.2007 |
| CADILLAC | STS 4.6 | [LH2] | 05.2005-12.2007 |
| CADILLAC | STS 4.6 | 01.2005-12.2010 | |
| CADILLAC | STS 4.6 AWD | [LH2] | 09.2004-12.2005 |
Reference Information
A-80282 12571 ALN3261NW 90-29-5538 554475RI DRA1097 UD11371A 104210-3260 104210-3261 ALN3261 25756440 A-80325 11038RVideo/Publications
104210-3260 104210-3261 11038R 12571 25756440 554475RI 90-29-5538 A-80282 A-80325 ALN3261 ALN3261NW DRA1097 UD11371AAdd Your Number
