- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
156.001.050 20137476BN 20137476OE 2035674 48-1874 553347RI 554452RI A-0061 A2T70771 A2T70772 A2T70774 A2T70776 A2T70777 A4T57472 AEU1327 CAL35674AS CAL35674GS LRA02459 ME049154 ME067611 SS072 UD11276A UNITBOM203-158Specifications
| Amp | 30 A |
| Bottom Mounting Foot Width (B) | 12.5 mm |
| Diameter (D.1) | M12x1.25 mm |
| Diameter (D.2) | 12.5 mm |
| Diameter (D.3) | 12.5 mm |
| Grooves | 2 qty |
| Groove Width (W.1) | 16 mm |
| Length (L.1) | 196 mm |
| Mount Inside Length or Pad Mount C-C (C) | 82 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 50 mm |
| Outside Diameter (O.D.2) | 82 mm |
| Plug Code | PL_2003 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 44 mm |
| Pulley Type | SOLID |
| Unit Type | MITSUBISHI |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KOBELCO | Engine | [6D15] | |
| KOBELCO | Engine | [6D22C] | |
| KOBELCO | Engine | [6D22C-T] | |
| KOBELCO | Engine | [8DC8] | |
| KOBELCO | Engine | [8DC9] | |
| KOBELCO | Engine | [8DC9-T] | |
| KOBELCO | K912A | [6D22] | 01.1985-12.1987 |
Reference Information
A2T70774 A2T70776 A2T70777 LRA02459 A002T70777 A002T70776 20137476OE A002T70774 156.001.050 48-1874 A002T70772 A002T70771 CGB-13613 553347RI A2T70771 554452RI A2T70772 LRA2459 SS072 A002T72189 A002T72986 ME049165 20137476BN ME067611 A2T72986 A4T57472 AEU1327 ME067617 12308N CAL35674AS UD11276A A2T72189 UNITBOM203-158 2035674 ME049154 A-0061 CAL35674GS A004T57472Video/Publications
156.001.050 20137476BN 20137476OE 2035674 48-1874 553347RI 554452RI A-0061 A2T70771 A2T70772 A2T70774 A2T70776 A2T70777 A4T57472 AEU1327 CAL35674AS CAL35674GS CGB-13613 LRA02459 LRA2459 ME049154 ME067611 SS072 UD11276A UNITBOM203-158 ME067617Add Your Number
