- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Add Your Number
Associated Numbers
0986044841 112462 12312247389 12312247405 22955N 22955R 2542218 2542251 2542251A 28-3851 301559RI 301559RIV 32044841 437116 439235 8EL011711-541 8EL737813-001 A14VI28 A3201 AEC1559 ALT14214 CA1559IR DRA3809 EAA-221591 GA439459-A LRA01955 NA530Specifications
| Amp | 120 A |
| Bottom Mounting Foot Width (B) | 28 mm |
| Diameter (D.1) | 10.5 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.5 mm |
| Grooves | 5 qty |
| Length (L.1) | 190 mm |
| Mount Inside Length or Pad Mount C-C (C) | 75 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 53.5 mm |
| Plug Code | PL_3406 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 60 mm |
| Pulley Type | SOLID |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| BMW | 320 2.0 Diesel | (E46)[M47204D1] | 02.1998-04.2005 |
| BMW | 320 2.0 Diesel | (E46)[M47D20] | 04.1998-09.2001 |
| BMW | 330 2.9 Diesel | (E46)[M57D30] | 10.1999-02.2005 |
| BMW | 520 2.0 Diesel | (E39)[M47204D1] | 02.2000-06.2003 |
| BMW | 520 2.0 Diesel | (E39)[M47204D1] | 02.2000-09.2003 |
| BMW | 520 2.0 Diesel | (E39)[M47D20] | 02.2000-06.2003 |
| BMW | 520 2.0 Diesel | (E39)[M47D20] | 02.2000-09.2003 |
| BMW | 525 2.5 Diesel | (E39)[M57D25] | 02.2000-05.2004 |
| BMW | 525 2.5 Diesel | (E39)[M57D25] | 02.2000-06.2003 |
| BMW | 530 2.9 Diesel | (E39)[M57D30] | 08.1998-09.2000 |
| BMW | 530 2.9 Diesel | (E39)[M57D30] | 09.2000-06.2003 |
| BMW | 530 2.9 Diesel | (E39)[M57D30 (306D1)] | 09.2000-05.2004 |
| BMW | 530 2.9 Diesel | (E39)[M57D30(306D1)] | 09.2000-05.2004 |
| BMW | 530 2.9 TD | (E39)[M57D30] | 08.1998-09.2000 |
| BMW | 730 3.0 Diesel | (E38)[M57D30] | 08.1998-04.2000 |
| BMW | 75 2.0 CDT | [M47] | 02.1999- |
| BMW | 75 2.0 CDT | [M47] | 08.2001- |
| BMW | 75 2.0 CDTi | [204D2] | 02.2003- |
| BMW | X5 3.0 Diesel | (E53)[M57D30(306D1)] | 05.2001- |
| BMW | Z3 3.2 | (E36)[S54326S4] | 06.2001-01.2003 |
| BMW | Z3 3.2 | (E36)[S54B32] | 06.2001-01.2003 |
| LAND ROVER | Freelander 2.0 TD4 | [204D3] | 11.2000- |
| LAND ROVER | Freelander 2.0 TD4 | [M47] | 11.2001- |
| MG | ZT 2.0 CDTi | [M47(204D2)] | 11.2002- |
| MG | ZT-T 2.0 CDTi | [M47(204D2)] | 11.2002- |
| ROVER | 75 2.0 CDT | [M47] | 02.1999- |
| ROVER | 75 2.0 CDT | [M47] | 08.2001- |
| ROVER | 75 2.0 CDTi | [204D2] | 02.2003- |
Reference Information
CAL15266GS 441706 89213844 9.44391E+11 455.507.120.000 2542251B 2542251A 2247389 210868 130719 32044841 AEC1559 439235 GA439459-A 4189 12312247389 746114 LEA1019 LRA1955 22955R 301559RI 002-H301 ALT0037 ANM36029X 22955N 8EL737813-001 2H301 ALTL118 0986044841 455.507.120.505 455.507.120.500 8EL011711-542 A14VI28 A3201 CA1559IR ALT172770 ALT14214 8EL011711-541 986044841 746914 NA530 2247405 301559RIV 437116 CAL15266AS PRAL118 EAA-221591 ALT0083 DRA3809 2015266.1 LRA01955 2542218 CGB-83851 2015266.2 A12VA0333A2 ALH301 12312247405 63730025010 CAL15266RS 2542251 28-3851 ALT7920 63731559010 112462 2015266 CGB-13809 56847Video/Publications
002-H301 0986044841 112462 12312247389 12312247405 22955N 22955R 2542218 2542251 2542251A 28-3851 2H301 301559RI 301559RIV 32044841 437116 439235 8EL011711-541 8EL737813-001 A14VI28 A3201 AEC1559 ALH301 ALT14214 ALT172770 ALT7920 ALTL118 CA1559IR CGB-13809 DRA3809 EAA-221591 GA439459-A LRA01955 LRA1955 MAV2360 NA530 210868Add Your Number
Contact Details
Request More Information
Add your number to the message box below and we will add it to our system
View your shopping basket or Browse other items in Alternators.
